Description | Value |
---|---|
Technical product number | 5514746 |
Identifying order number | TNMG 160408 MT TT5100 |
Company code | IL - Ingersoll |
Standard number of properties layout | DIN4000-76 |
Tool style code | 1 |
Insert included angle | 60 Degree |
Clearance angle major | 0 Degree |
Cutting edge length | 14.5 mm |
Inscribed circle diameter | 9.52 mm |
Insert thickness | 4.76 mm |
Corner radius | 0.8 mm |
Chip breaker face count | 0 - Without chip breaker |
Cutting edge effective length | 2 mm |
Insert hand | N - Neutral |
Tolerance class insert | M |
Insert thickness total | 4.76 mm |
Insert mounting style code | 2 - With cylindrical bore |
Standard designation of the grade, main application | P20-P35 |
Standard designation of the grade, 2nd application | M20-M35 |
Grade manufacturer's designation | TT5100 |
Coating | TiCN+Al2O3+TiN |
ISO property | 1 |
Standard designation | TNMG160408 |
Standard designation ANSI | TNMG332 |
Master insert identification | TNMG160408 TT5100 |
